MASI67 INSTALLATION TECHNOLOGY
Product may differ from image

MASI67 INSTALLATION TECHNOLOGY

Converter 2x profile cable to M12 male
Art.No.: 55038
Weight: 0.12 kg
In production
 Product Comparison
List price per piece:
MASI67 converter
2× profile cable to M12 (male)
Connection cables are in the online shop under "Connection Technology".
Technical Data
Operating voltage max. 36 V DC
Total current max. 4 A
General data
Test isolation voltage AS-Interface/Power 200 V, (EN 60664-1)
Protection IP67
Mounting method DIN-rail mountable (EN 60715) or screw fixing
Temperature range -20...+60 °C (storage temperature -40...+80 °C)
Dimensions H×W×D 90×74×39 mm
Contact Layout
PIN 1 AS-Interface + (brown)
PIN 2 0 V (blue)
PIN 3 AS-Interface - (blue)
PIN 4 +24 V (brown)
PIN 5 n.c.
Commercial data
country of origin DE
customs tariff number 85369010
EAN 4048879052139
eClass 27400209
Packaging unit 1

Data Regarding Article:
  • Download Data Sheet
  • Download Approval: UL Registered CA 55038_E201820-NRAQ8_urc_z_b.pdf
  • Download Approval: UL Registered US 55038_E201820-NRAQ2_ur_z_b.pdf
  • Download Construction files: DXF 55038_dxf_x_a.zip
  • Download Construction files: P8 55038_p8_2_50.zip
  • Download Construction files: P8 55033_p8_2_50.zip
  • Download Construction files: STP 55038_stp_x_a.zip
  • Download Document: Installation guide 55038_ina_2_16.pdf
  • Download Information: China-RoHS EPUP-20_CHR_x_1.pdf
cURus
